Summit Ascent Trainer
with
DLED Console
Count on our variable stride and incline for versatile, low-impact workouts in demanding fitness environments.
- Footprint 10% smaller than competitors delivers maximum performance in minimal space
- Variable stride and incline target different muscles through varied workout motions
- Wheel- and track-free design delivers smooth, quiet, low-friction performance
Product availability may vary by region. Please contact your local office for more information.
Select a Console
A Sleeker, Smoother LED Experience
The DLED Console pairs bright workout feedback, intuitive controls and simple connectivity in a clean, easy-to-use design.
DLED Console
Sleek Modern Design
A slim console case brings the sleek aesthetic of a modern exercise experience to your facility.
Elevate Every Ascent
Compact Footprint for More Training Space
A footprint 10% smaller than competitive designs helps maximize floor space without limiting workout variety or user comfort.
Quiet Wheel-Free, Track-Free Design
The wheel- and track-free design reduces friction, noise and wear, supporting smooth motion and dependable performance over time.
Smooth Resistance for Interval Training
Smooth, instant resistance changes support Sprint 8, HIIT and other interval workouts, helping users move between effort levels without interrupting workout flow.
Low Step-On Height for Easy Access
A low step-on height and well-placed handholds help users enter and exit the Ascent Trainer with greater confidence.
Built for Busy Fitness Facilities
Stable Frame for Confident Movement
A stable commercial frame supports smooth, controlled movement during demanding cardio workouts and frequent daily use.
Internal Component Protection
Sweat-resistant design helps protect internal components, supporting dependable operation in busy fitness environments.
Easy Service Access Reduces Downtime
Easy-access service points simplify routine maintenance and help return equipment to use sooner.
Explore the Ascent Trainer Up Close
Specifications
Product features and specifications subject to change.
Console
Display
14 x 10 dot-matrix workout profile LEDs and 22 numeric LEDs
Workouts
Go, manual, fat burn, intervals, constant watts†, goal, target heart rate, fitness tests
†Some of these programs may not be available on this frame.
Languages
English, German, French, Italian, Spanish, Dutch, Portuguese, Russian, Polish
WiFi
Optional: for connection to Vision Asset Management
Bluetooth
Yes: connection to Vision Fitness app, heart rate device or FTMS-enabled fitness app
USB Port
Yes: USB-A for device charging and software updates
Workout Feedback
5 displays allow user to toggle between time and distance, resistance level and calories, speed and RPM, watts and METS, heart rate and incline
NFC
Yes: one-tap connection to Vision Fitness app
Tablet Holder
Yes
QR Code
Yes: connects to console demonstration video and Vision Fitness app download link
Power consumption when turned off
≤ 0.3 W
Power consumption in standby mode
≤ 0.5 W
Frame
Frame Type
Ascent Trainer
Variable Stride Length
52–57.5 cm / 20”–23”
Step-on Height
21.6 cm / 8.5”
Power Incline
15%–37%
Resistance System
Two-stage, self-powered generator
Resistance Range
1–30
Pedal Type
Oversized with rubber inserts and front guard
Pedal Spacing
5.9 cm / 2.3”
Handlebar Design
Dual action and stationary with heart rate grips
Extras
Water bottle holder, reading rack
Assembled Dimensions (L x W x H)
182 x 84 x 171 cm / 71.6” x 33” x 67”
Assembled Weight
155 kg / 341.7 lbs.
Max User Weight
182 kg / 400 lbs.
Power Requirements
100–240 V — 50/60 Hz AC (may vary by region)
Power Supply
NEMA 6–20 (220 V) or NEMA 5–15 (100–120 V) (requirement may vary by region)
